Made in USA - Panel Rivets Type: Panel Rivet Shank Type: Standard
Item #: 19287184
Brand: Made in USA
Model #:
Features and Benefits
Panel rivets are inserted into punched or predrilled holes in thin materials. They are push-in fasteners that resist shaking, vibration, loosening and abrasion.
Product Specifications
Panel Rivets; Type: Panel Rivet ; Shank Type: Standard ; Head Type: Flat ; Minimum Hole Diameter (Decimal Inch): 0.2030 ; Maximum Hole Diameter (Decimal Inch): 0.2030 ; Minimum Material Thickness (Decimal Inch): 0.0600
| Type | Panel Rivet |
| Shank Type | Standard |
| Head Type | Flat |
| Minimum Hole Diameter (Decimal Inch) | 0.2030 |
| Maximum Hole Diameter (Decimal Inch) | 0.2030 |
| Minimum Material Thickness (Decimal Inch) | 0.0600 |
| Maximum Material Thickness (Decimal Inch) | 0.4800 |
| Head Diameter (Decimal Inch) | 0.7500 |
| Head Height (Decimal Inch) | 0.0650 |
| Length Under Head (Decimal Inch) | 0.7000 |
| Overall Length (Decimal Inch) | 0.76500 |
| Body Diameter (Decimal Inch) | 0.2240 |
| Color | Black |
| Material | Nylon |
