CV50TTGL10M315 SHRINK
Item #: WK526199553
Brand: Widia
Model #: 6199553
| Product Specifications | |
|---|---|
| Connection Diameter Workpiece Side (DCONWS) | 10 mm |
| Thread Designation Inside (THID) | 1″ - 8 |
| Shank Size (SS) | CV50 |
| Tool Type | Shrinkfit Holders |
| Body Diameter (BD) | 24 mm |
| Coolant Supply Property (CSP) | Coolant Thru |
| Body Diameter_2 (BD_2) | 32 mm |
| Clamping Length Workpiece Side (LSCWS) | 32 mm |
| Protruding Length (LPR) | 80 mm |
| Usable Length (LU) | 60.9 mm |
| Overall Length (OAL) | 181.6 mm |
| Series/List # | CV50 |
| Shank Type | CV-Caterpillar V-Flange In |
