DV50BWN25080M ADAPTER
Item #: WK521136842
Brand: Widia
Model #: 1136842
| Product Specifications | |
|---|---|
| Protruding Length (LPR) | 80 mm |
| Shank Type | DV-DIN69871 |
| Connection Diameter Machine Side (DCONMS) | 69.85 mm |
| Cutting Direction (HAND) | Neutral |
| Connection Diameter Workpiece Side (DCONWS) | 25 mm |
| Series/List # | DV50 |
| Clamping Length Workpiece Side (LSCWS) | 44 mm |
| Measurement Type | Metric |
| Thread Diameter Size (TDZ) | M24 × 3 |
| Body Diameter_2 (BD_2) | 69.85 mm |
| Body Diameter (BD) | 64.5 mm |
| Shank Length (LS) | 104.8 mm |
| Functional Length (LF) | 80 mm |
| Overall Length (OAL) | 181.6 mm |
| Coolant Supply Property (CSP) | Coolant Thru |
| Connection Code Machine Side (CCMS) | DV50 |
