Brand: Widia / Part #: 3896119
Item #: 98772395
Brand: Widia
Model #: 3896119
Product Specifications
| Bore Diameter (mm) | 3.9700 |
| Bore Diameter (Decimal Inch) | 5/32 |
| Bore Depth (mm) | 13.97 |
| Connection Size | 0.5000 in |
| Body Diameter (mm) | 19.300 |
| Coolant Style | Internal |
| Material | Steel |
| Overall Length (Decimal Inch) | 4.0000 |
| Overall Length (mm) | 101.6000 |
| Type | ATBI |
| Body Length (Decimal Inch) | 0.7500 |
| Head Style | Angled |
| Body Length | 19.050 |
