Scientific Cutting Tools - 3/8-24" Port, 3/8" Spotface Diam, 3/16" Tube Outside Diam, Plain Pilot, Solid Carbide Porting Tool
Item #: 44075554
Brand: Scientific Cutting Tools
Model #: MS33514-3A
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Port Standard Designation | AS 33514; MS 33514 |
| Pilot Type | Plain |
| Port Thread Size (Decimal Inch) | 0.3750-24 |
| Port Thread Size (Inch) | 3/8-24 |
| Tool Material | Solid Carbide |
| Tube Dash Number | 3.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 0.188 |
| Tube Outside Diameter Compatibility (Inch) | 3/16 |
| Minimum Pilot Diameter (Decimal Inch) | 0.1230 |
| Maximum Pilot Diameter (Decimal Inch) | 0.1980 |
| Spotface Diameter (Decimal Inch) | 0.3750 |
| Pilot Length (Decimal Inch) | 0.2260 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 1.0000 |
| Overall Length (Decimal Inch) | 3.0000 |
| Shank Diameter (Decimal Inch) | 0.3750 |
| Shank Length (Decimal Inch) | 2.0000 |
| Seal Angle | 12 |
| Thread Type | UNJF |
| Flute Type | Straight |
| Number of Flutes | 3 |
