Brand: Ingersoll Cutting Tools / Part #: 2915843

Brand: Ingersoll Cutting Tools / Part #: 2915843


Item #: 67318774
Brand: Ingersoll Cutting Tools
Model #: 2915843

Product Specifications

Insert Style SDXS
Insert Size Code 1305
Insert Material Carbide
Manufacturer Grade IN2530
Inscribed Circle (mm) 13.00
Insert Hand Right Hand
Series SDXS
Coating Process PVD
Maximum Depth of Cut (mm) 11.40
Number Of Cutting Edges 4
Insert Shape Square
Rake Positive
Primary Workpiece Material Stainless Steel; Cast Iron; Super-alloys & Titanium; Steel
Primary Workpiece Material Code P; S; K; M
Ansi Code SDXS1305MPR-MR J
Rake Angle 15.000
Manufacturers Catalog Number SDXS1305MPR-MR J IN2530
Cutter Series Compatibility 15M1P; 5M5P; 5M6P
Chip Breaker MR
Cutting Direction Right Hand
Shape Square
Insert Holding Method Screw
Coating Classification PVD
Single or Double Sided Insert Single
Coating/Finish TiN; TiAlN
Included Angle Degree 90
Length 13.00
Width (Mm - 2 Decimals) 13.00
Thickness (Decimal Inch - 4 Decimals) 0.2000
Multi-Use Tool No
$18.32
