Brand: SGS / Part #: 00699
Item #: 60059862
Brand: SGS
Model #: 00699
Product Specifications
| Mill Diameter (Decimal Inch) | 0.0350 |
| End Mill Material | Solid Carbide |
| Coating/Finish | Uncoated |
| Number Of Flutes | 2 |
| Extended Reach | No |
| Helix Angle | 30 |
| Variable Index | No |
| Length Of Cut Range (Decimal Inch) | 0.0500 to 0.1000 |
| Variable Helix | No |
| Length Type | Stub |
| Shank Diameter (Inch) | 1/8 |
| Overall Length (Inch) | 1-1/2 |
| Mill Diameter Tolerance | +0.0000 to -0.0008 in |
| Material Grade | Micrograin |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Series | 1635 |
| Flute Type | Spiral |
| Single Or Double End | Single |
| Length Of Cut (Decimal Inch - 4 Decimals) | 0.0530 |
