Abbott Workholding Products - Soft Lathe Chuck Jaws Jaw Type: Round Material: Aluminum
Item #: 50484500
Brand: Abbott Workholding Products
Model #: TG15MDP
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
Product Specifications
Soft Lathe Chuck Jaws; Jaw Type: Round ; Material: Aluminum ; Jaw Interface Type: Tongue & Groove ; Maximum Compatible Chuck Diameter (Inch): 15 ; Maximum Compatible Chuck Diameter (Decimal Inch): 15.0000 ; Maximum Compatible Chuck Diameter (mm): 381.00
| Jaw Type | Round |
| Material | Aluminum |
| Jaw Interface Type | Tongue & Groove |
| Maximum Compatible Chuck Diameter (Inch) | 15 |
| Maximum Compatible Chuck Diameter (Decimal Inch) | 15.0000 |
| Maximum Compatible Chuck Diameter (mm) | 381.00 |
| Minimum Compatible Chuck Diameter (Decimal Inch) | 15.0000 |
| Overall Height (mm) | 76.20 |
| Overall Height (Inch) | 3 |
| Groove Width (mm) | 12.70 |
| Groove Width (Decimal Inch) | 0.5000 |
| Distance Between Mount Hole Centers (mm) | 76.20 |
| Distance Between Mount Hole Centers (Decimal Inch) | 3.0000 |
| Tongue Width (Decimal Inch) | 0.7500 |
| Jaw End Shape | Pointed |
| Fastener Size (Inch) | 5/8 |
| Fastener Size (Decimal Inch) | 0.6250 |
| Number of Jaws | 3 |
| Overall Width/Diameter (mm) | 381.00 |
| Overall Width/Diameter (Inch) | 15 |
| Overall Width/Diameter (Decimal Inch) | 15.0000 |
| Material Grade | 6061 |
