Rotor Clip - 7/32" Shaft Diam, 0.205" Groove Diam, Beryllium Copper External SH Style Retaining Ring
Item #: 99622482
Brand: Rotor Clip
Model #: SH-21BC
Features and Benefits
SH style external retaining rings refer to shaft style and is applied externally onto the shaft of a workpiece. The SH ring is installed by separating the lugs, then being released into a groove.
Beryllium copper is the strongest of all copper alloys. It is nonmagnetic and resistant to some acids.
| Product Specifications | |
|---|---|
| Type | SH Style |
| System of Measurement | Inch |
| Shaft Diameter (Inch) | 7/32 |
| Groove Diameter (Decimal Inch) | 0.2050 |
| Free Diameter (Decimal Inch) | 0.1960 |
| Military Specification | Does Not Meet Military Specifications |
| Material | Beryllium Copper |
| Finish/Coating | Plain |
| Material Grade | UNS C17200 |
| Groove Width (Decimal Inch) | 0.0180 |
| Groove Depth (Decimal Inch) | 0.0070 |
| Ring Thickness (Decimal Inch) | 0.0150 |
| Groove Diameter Tolerance (Decimal Inch) | -0.0015 to 0.0015 |
| Groove Width Tolerance (Decimal Inch) | 0.000 to 0.002 |
| Free Diameter Tolerance (Decimal Inch) | -0.004 to 0.002 |
| Ring Thickness Tolerance (Decimal Inch) | 0.0020 to 0.0020 |
