McGill - 3-1/2" Roller Diam x 2" Width, 1-3/8" Stud Diam x 2-3/4" Length, Sealed Heavy Stud Cam Follower - Steel, 1-3/8" Thread Length, 1-3/4-12 Thread, 4.78" OAL, 22,800 Lb Dynamic Cap, 63,250 Lb Static Cap
Item #: 92611540
Brand: McGill
Model #: CFH 3 1/2 S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Heavy Stud Cam Follower |
| Roller Diameter (Decimal Inch) | 3.5000 |
| Roller Diameter (Inch) | 3-1/2 |
| Roller Width (Decimal Inch) | 2.0000 |
| Roller Width (Inch) | 2 |
| Stud Diameter (Decimal Inch) | 1.7500 |
| Dynamic Load Capacity (Lb.) | 22800 |
| Dynamic Load Capacity (N) | 101414 |
| Static Load Capacity (Pounds) | 63250.00 |
| Static Load Capacity | 281336 |
| Length (Decimal Inch) | 4.780 |
| Thread Size | 1-3/4-12 |
| Material | Steel |
| Stud Length (Decimal Inch) | 2.7500 |
| Stud Length (Inch) | 2-3/4 |
| Thread Length (Inch) | 1-3/8 |
| McGill Part Number | CFH 3 1/2 S |
| Roller Type | Needle Roller |
