McGill - 1" Roller Diam x 5/8" Width, 7/16" Stud Diam x 1" Length, Sealed Heavy Stud Cam Follower with Hex - Steel, 1/2" Thread Length, 5/8-18 Thread, 1.66" OAL, 2,225 Lb Dynamic Cap, 6,120 Lb Static Cap
Item #: 92611219
Brand: McGill
Model #: CFH 1 SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Heavy Stud Cam Follower with Hex |
| Roller Diameter (Decimal Inch) | 1.0000 |
| Roller Diameter (Inch) | 1 |
| Roller Width (Decimal Inch) | 0.6250 |
| Roller Width (Inch) | 5/8 |
| Stud Diameter (Decimal Inch) | 0.6250 |
| Dynamic Load Capacity (Lb.) | 2225 |
| Dynamic Load Capacity (N) | 9897 |
| Static Load Capacity (Pounds) | 6120.00 |
| Static Load Capacity | 27222 |
| Length (Decimal Inch) | 1.660 |
| Thread Size | 5/8-18 |
| Material | Steel |
| Stud Length (Decimal Inch) | 1.0000 |
| Stud Length (Inch) | 1 |
| Thread Length (Inch) | 1/2 |
| McGill Part Number | CFH 1 SB |
| Roller Type | Needle Roller |
