McGill - 3-1/4" Roller Diam x 1-3/4" Width, 1-1/4" Stud Diam x 2-1/2" Length, Sealed Heavy Stud Cam Follower with Hex - Steel, 1-1/4" Thread Length, 1-1/2-12 Thread, 4.28" OAL, 15,720 Lb Dynamic Cap, 49,820 Lb Static Cap
Item #: 92611128
Brand: McGill
Model #: CFH 3 1/4 SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Heavy Stud Cam Follower with Hex |
| Roller Diameter (Decimal Inch) | 3.2500 |
| Roller Diameter (Inch) | 3-1/4 |
| Roller Width (Decimal Inch) | 1.7500 |
| Roller Width (Inch) | 1-3/4 |
| Stud Diameter (Decimal Inch) | 1.5000 |
| Dynamic Load Capacity (Lb.) | 15720 |
| Dynamic Load Capacity (N) | 69923 |
| Static Load Capacity (Pounds) | 49820.00 |
| Static Load Capacity | 221599 |
| Length (Decimal Inch) | 4.280 |
| Thread Size | 1-1/2-12 |
| Material | Steel |
| Stud Length (Decimal Inch) | 2.5000 |
| Stud Length (Inch) | 2-1/2 |
| Thread Length (Inch) | 1-1/4 |
| McGill Part Number | CFH 3 1/4 SB |
| Roller Type | Needle Roller |
