McGill - 1/2" Roller Diam x 3/8" Width, 3/16" Stud Diam x 1/2" Length, Sealed Stud Cam Follower - Steel, 1/4" Thread Length, 10-32 Thread, 0.88" OAL, 620 Lb Dynamic Cap, 720 Lb Static Cap
Item #: 92610146
Brand: McGill
Model #: CF 1/2 N S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower |
| Roller Diameter (Decimal Inch) | 0.5000 |
| Roller Diameter (Inch) | 1/2 |
| Roller Width (Decimal Inch) | 0.3440 |
| Roller Width (Inch) | 3/8 |
| Stud Diameter (Decimal Inch) | 0.1900 |
| Dynamic Load Capacity (Lb.) | 620 |
| Dynamic Load Capacity (N) | 2758 |
| Static Load Capacity (Pounds) | 720.00 |
| Static Load Capacity | 3203 |
| Length (Decimal Inch) | 0.880 |
| Thread Size | 10-32 |
| Material | Steel |
| Stud Length (Decimal Inch) | 0.5000 |
| Stud Length (Inch) | 1/2 |
| Thread Length (Inch) | 1/4 |
| McGill Part Number | CF 1/2 N S |
| Roller Type | Needle Roller |
