McGill - 3" Roller Diam x 1-3/4" Width, 1-1/4" Stud Diam x 2-1/2" Length, Stud Cam Follower - Steel, 1-1/4" Thread Length, 1-1/4-12 Thread, 4.28" OAL, 15,720 Lb Dynamic Cap, 24,910 Lb Static Cap
Item #: 92610120
Brand: McGill
Model #: CF 3
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Stud Cam Follower |
| Roller Diameter (Decimal Inch) | 3.0000 |
| Roller Diameter (Inch) | 3 |
| Roller Width (Decimal Inch) | 1.7500 |
| Roller Width (Inch) | 1-3/4 |
| Stud Diameter (Decimal Inch) | 1.2500 |
| Dynamic Load Capacity (Lb.) | 15720 |
| Dynamic Load Capacity (N) | 69923 |
| Static Load Capacity (Pounds) | 24910.00 |
| Static Load Capacity | 110800 |
| Length (Decimal Inch) | 4.280 |
| Thread Size | 1-1/4-12 |
| Material | Steel |
| Stud Length (Decimal Inch) | 2.5000 |
| Stud Length (Inch) | 2-1/2 |
| Thread Length (Inch) | 1-1/4 |
| McGill Part Number | CF 3 |
| Roller Type | Needle Roller |
