McGill - 1-3/4" Roller Diam x 1-3/16" Width, 3/4" Stud Diam x 1-3/4" Length, Flanged Load Roller - Steel, 7/8" Thread Length, 3/4-16 Thread, 2.94" OAL, 2,520 Lb Dynamic Cap, 1,370 Lb Static Cap
Item #: 92609973
Brand: McGill
Model #: FCF 1 3/4
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Flanged Load Roller |
| Roller Diameter (Decimal Inch) | 1.7500 |
| Roller Diameter (Inch) | 1-3/4 |
| Roller Width (Decimal Inch) | 1.1880 |
| Roller Width (Inch) | 1-3/16 |
| Stud Diameter (Decimal Inch) | 0.7500 |
| Dynamic Load Capacity (Lb.) | 2520 |
| Dynamic Load Capacity (N) | 11209 |
| Static Load Capacity (Pounds) | 1370.00 |
| Static Load Capacity | 6094 |
| Length (Decimal Inch) | 2.940 |
| Thread Size | 3/4-16 |
| Material | Steel |
| Flange Diameter (Decimal Inch) | 2.4400 |
| Flange Thickness (Decimal Inch) | 0.3400 |
| Stud Length (Decimal Inch) | 1.7500 |
| Stud Length (Inch) | 1-3/4 |
| Thread Length (Inch) | 7/8 |
| Hex Size (Inch) | 1/4 |
| McGill Part Number | FCF 1 3/4 |
| Roller Type | Ball Bearing |
