Brand: Widia / Part #: 5094214
Item #: 97247381
Brand: Widia
Model #: 5094214
Product Specifications
| Cutting Direction | Right Hand |
| Hand of Holder | Right Hand |
| Compatible Insert Size Code | CP..2151 |
| Toolholder Style | SCLPR |
| Rake | Positive |
| Rake Angle | 3.5 |
| Multi-use Tool | Yes |
| Lead Angle | 95.000 |
| Insert Holding Method | Screw |
| Shank Width (Decimal Inch) | 0.3750 |
| Shank Width (Inch) | 3/8 |
| Shank Height (Decimal Inch) | 0.3750 |
| Shank Height (Inch) | 3/8 |
| Series | SCLP |
| Overall Length (Decimal Inch) | 2.5000 |
| Overall Length (Inch) | 2-1/2 |
| Cutting Tool Application | Turning |
| Head Length (Decimal Inch) | 0.4400 |
| Back of Bar to Cutting Edge (Inch) | 1/2 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.5000 |
| Primary Workpiece Material | Universal |
| Center to Cutting Edge (Decimal Inch) | 0.3125 |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Insert Inscribed Circle (Inch) | 1/4 |
| Insert Width (Decimal Inch) | 0.2540 |
| Toolholder Material | Steel |
| ISO Number | SCLPR062 |
| Complete Insert Compatibility | CP..21.5. |
| Manufacturers Catalog Number | SCLPR062 |
| Coolant Through | No |
| Insert Thickness (Decimal Inch) | 0.0940 |
