McGill - 4" Roller Diam x 2-1/4" Width, 1-1/2" Stud Diam x 3-1/2" Length, Stud Cam Follower - Steel, 1-1/2" Thread Length, 1-1/2-12 Thread, 5.78" OAL, 22,800 Lb Dynamic Cap, 44,770 Lb Static Cap
Item #: 92609593
Brand: McGill
Model #: CF 4
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Stud Cam Follower |
| Roller Diameter (Decimal Inch) | 4.0000 |
| Roller Diameter (Inch) | 4 |
| Roller Width (Decimal Inch) | 2.2500 |
| Roller Width (Inch) | 2-1/4 |
| Stud Diameter (Decimal Inch) | 1.5000 |
| Dynamic Load Capacity (Lb.) | 22800 |
| Dynamic Load Capacity (N) | 101414 |
| Static Load Capacity (Pounds) | 44770.00 |
| Static Load Capacity | 199137 |
| Length (Decimal Inch) | 5.780 |
| Thread Size | 1-1/2-12 |
| Material | Steel |
| Stud Length (Decimal Inch) | 3.5000 |
| Stud Length (Inch) | 3-1/2 |
| Thread Length (Inch) | 1-1/2 |
| McGill Part Number | CF 4 |
| Roller Type | Needle Roller |
