Live Center: Morse Taper Shank 12,000 lb Workpiece Weight, 7,000 Max RPM, Extended Point
Item #: 90423534
Brand: Bison
Model #: 7-560-002
Product Specifications
| Shank Type | Morse Taper |
| Bearing Type | Triple |
| Material | Steel |
| Taper Size | MT2 |
| Maximum Workpiece Weight (Lb.) | 12000.00 |
| Maximum Workpiece Weight (kg) | 125.00 |
| Point Style | Extended |
| Point Diameter (mm) | 20.00 |
| Tip Diameter (mm) | 10.00 |
| Tip Diameter (Decimal Inch) | 10.0000 |
| Tip Diameter (Inch) | 10 |
| Point Length (mm) | 33.50 |
| Accuracy (Decimal Inch) | 0.000200 |
| Accuracy | 2.0E-4 in; 0.005 mm |
| Thrust Load (Lb.) | 1012.00 |
| Thrust Load (daN) | 450.00 |
| Radial Load | 275 lb |
| Head Diameter (mm) | 45.00 |
| Taper Length (Decimal Inch) | 2.5197 |
| Point to Gauge Line (mm) | 74.50 |
| Included Angle | 60 |
| Maximum RPM | 7000 |
| Carbide-tipped Point | No |
