Open-Center Hydraulic Lathe Cylinders; Material: AC2B; SCM415; Bore Size (mm): 166.50; Piston Diameter: 305.000; Piston Push Force: 152 kN; Piston Pull Force: 138 kN; Thread Size (Metric): M180 x 3.0; Maximum Rpm: 2000.000; Maximum Operating Pressure: 3.3
Item #: 90027038
Brand: Samchully
Model #: SDL-30516CA
Product Specifications
| Material | AC2B; SCM415 |
| Bore Size (mm) | 166.50 |
| Piston Diameter | 305.000 |
| Piston Push Force | 152 kN |
| Piston Pull Force | 138 kN |
| Thread Size (Metric) | M180 x 3.0 |
| Maximum Rpm | 2000.000 |
| Maximum Operating Pressure | 3.3 kgf/cm? |
| Total Leakage | 8.4 |
| Overall Width | 24 |
| Overall Height | 24 in |
| Overall Depth | 24 in |
