Open-Center Hydraulic Lathe Cylinders; Material: AC2B; SCM415; Bore Size (mm): 36.00; Piston Diameter: 105.000; Piston Push Force: 25 kN; Piston Pull Force: 24 kN; Thread Size (Metric): M42 x 1.5; Maximum Rpm: 8000.000; Maximum Operating Pressure: 4.0 kgf
Item #: 90003930
Brand: Samchully
Model #: SD-10536S-CUH
Product Specifications
| Material | AC2B; SCM415 |
| Bore Size (mm) | 36.00 |
| Piston Diameter | 105.000 |
| Piston Push Force | 25 kN |
| Piston Pull Force | 24 kN |
| Thread Size (Metric) | M42 x 1.5 |
| Maximum Rpm | 8000.000 |
| Maximum Operating Pressure | 4.0 kgf/cm? |
| Total Leakage | 1.2 |
| Overall Width | 10 |
| Overall Height | 10 in |
| Overall Depth | 10 in |
