Gibraltar - M20x1.5, 35mm Thread Length, Straight Cam Action Indexing Plunger - 20mm Body Diam, 35mm Body Length, 50mm Handle Length, 12mm Plunger Projection
Item #: 88363973
Brand: Gibraltar
Exact Tooling IR#: 04
Features and Benefits
Stainless steel is made of iron and chromium and is resistant to rust and corrosion. It offers high tensile strength and can be used in several environments.
| Product Specifications | |
|---|---|
| Thread Size | M20x1.5 |
| Thread Length (mm) | 35.00 |
| Plunger Diameter (mm) | 8.00 |
| Body Diameter (mm) | 20.00 |
| Body Length (mm) | 35.00 |
| Handle Length (mm) | 50.00 |
| Plunger Projection (mm) | 12.00 |
| Plunger Type | Straight |
| Initial End Force (N) | 20.00 |
| Final End Force (N) | 60.00 |
| Handle Width/Diameter (mm) | 18.00 |
| Overall Length (mm) | 70.00 |
| Material | Stainless Steel |
| Finish/Coating | Natural |
| Tolerance (mm) | -0.04; -0.02 |
