Climax Metal Products - M6 Thread, 40mm Bore Diam, 65mm OD, Shaft Locking Device - 14 Screws, 12,486 Lb Axial Load, 2.559" OAW, 0.669" Thrust Ring Width, 819 Ft/Lb Max Torque
Item #: 87793741
Brand: Climax Metal Products
Model #: C200M-40X65
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M6 |
| Bore Diameter (mm) | 40.000 |
| Outside Diameter (mm) | 65.0000 |
| Thrust Ring Width (Decimal Inch) | 0.669 |
| Overall Width (Decimal Inch) | 2.5590 |
| Axial Load Lbs (Pounds) | 12486 |
| Maximum Torque (Ft/Lb) | 819 |
| Number of Screws | 14.000 |
| Contact Pressure on Hub (psi) | 19338.000 |
| Contact Pressure on Shaft (psi) | 31424.000 |
| Screw Seating Torque (In/Lb) | 120.000 |
