Climax Metal Products - M10 Thread, 3-1/2" Bore Diam, 5.118" OD, Shaft Locking Device - 9 Screws, 34,204 Lb Axial Load, 5.472" OAW, 0.945" Thrust Ring Width, 4,988 Ft/Lb Max Torque
Item #: 87793600
Brand: Climax Metal Products
Model #: C133E-350
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M10 |
| Bore Diameter (Decimal Inch) | 3.5000 |
| Outside Diameter (Decimal Inch) | 5.1180 |
| Thrust Ring Width (Decimal Inch) | 0.945 |
| Overall Width (Decimal Inch) | 5.4720 |
| Axial Load Lbs (Pounds) | 34204 |
| Maximum Torque (Ft/Lb) | 4988 |
| Number of Screws | 9.000 |
| Contact Pressure on Hub (psi) | 18761.000 |
| Contact Pressure on Shaft (psi) | 27434.000 |
| Screw Seating Torque (In/Lb) | 732.000 |
