US Motors - 30 hp, TEFC Enclosure, No Thermal Protection, 1,775 RPM, 460 Volt, 60 Hz, Three Phase Standard Efficient Motor - Size 326 Frame, C-Face Mount, Ball Bearings, 35.0 Full Load Amps, F Class Insulation, CCW Lead End
Item #: 86336211
Brand: US Motors
Model #: A30S2CSCR
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Motor Type | Three Phase Standard Efficient |
| Type of Enclosure | TEFC |
| Horsepower | 30 |
| Thermal Protection Rating | None |
| Name Plate RPMs | 1775 |
| Voltage | 460 |
| Frequency Hz | 60 |
| Frame Size | 326 |
| Mount Type | C-Face |
| Bearing Type | Ball |
| Applications | Definite Purpose |
| Full Load Amperage | 35.0 |
| Insulation Class | F |
| Frame Material | Cast Iron |
| Overall Length (Decimal Inch) | 29.5600 |
| Service Factor Rating | 1.15 |
| Motor Rotation | CCW Lead End |
| PSC Code | 6105 |
