ARO/Ingersoll-Rand - 1/4" NPT Port Compact 2 Piece Filter/Regulator-Lubricator FRL Unit - Metal Bowl, 58 SCFM, 250 Max psi, 8.15" High x 4.409" Long, Manual Drain
Item #: 85102564
Brand: ARO/Ingersoll-Rand
Model #: C38221-610
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Configuration | 2 Pc. Filter/Regulator-Lubricator |
| Body Type | Compact |
| Port Size NPT | 1/4 |
| Maximum Supply Pressure (psi) | 250.00 |
| Height (Inch) | 8.15 |
| Width (Decimal Inch) | 3.3290 |
| Bowl Material | Metal |
| Standard Cubic Feet Per Minute | 58.00 |
| Includes Sight Glass | Yes |
| Bowl Guard | No |
| Filter Bowl Capacity (oz.) | 1.3 |
| Drain Type | Manual |
| Gauge Port Size (Inch) | 1/8 |
| Pressure Gauge Included | Yes |
| Minimum Temperature (F) | 23 |
| Maximum Temperature (F) | 175 |
| Micron Rating | 5 |
| Series | 1500 |
| Range | 0 - 140 |
| Modular Connection | Yes |
| Material | Aluminum |
