De-Sta-Co - 2,495 Lb Capacity, 1-1/4" Plunger Travel, 3/8-16 x 0.62" Plunger, 1/8 NPT Port, 3,582 N at 5 Bar, Air Power Straight Line Action Clamp
Item #: 84031517
Brand: De-Sta-Co
Model #: 830-LC
Product Specifications
| Power Type | Pneumatic |
| Load Capacity (N) | 11100.00 |
| Load Capacity (Lb.) | 2495.38 |
| Plunger Travel (mm) | 31.75 |
| Plunger Travel (Decimal Inch) | 1.2500 |
| Plunger Thread Size | 3/8-16 |
| Plunger Diameter (mm) | 15.75 |
| Plunger Diameter (Decimal Inch) | 0.6200 |
| Port Size | 1/8 NPT |
| Clamping Force @ 5 Bar (N) | 3582.00 |
| Plunger Centerline Height (mm) | 26.92 |
| Plunger Centerline Height (Decimal Inch) | 1.0600 |
| Overall Closed Length (mm) | 340.36 |
| Overall Closed Length (Decimal Inch) | 13.40 |
| Overall Closed Height (mm) | 91.19 |
| Overall Closed Height (Decimal Inch) | 3.59 |
| Mounting Hole Diameter (mm) | 8.64 |
| Mounting Hole Diameter (Decimal Inch) | 0.3400 |
| Length Distance Between Mount Holes (mm) | 35.05; 41.15 |
| Length Distance Between Mount Holes (Decimal Inch) | 1.3800; 1.6200 |
| Width Distance Between Mount Holes (mm) | 1051.56 |
| Width Distance Between Mount Holes (Decimal Inch) | 41.4000 |
| Maximum Air Pressure (psig) | 145.00 |
| Maximum Air Pressure (bar) | 10.00 |
| Sensor Compatibility | Round; T-Slot |
| Minimum Operating Temperature (F) | 14.00 |
| Minimum Operating Temperature (C) | -10.00 |
| Maximum Operating Temperature (F) | 194.00 |
| Maximum Operating Temperature (C) | 90.00 |
