Graymills - 230/460 Volt, 1/4 hp, 3 Phase, 3,450 RPM, Cast Iron Immersion Machine Tool & Recirculating Pump - 20 GPM, 32 psi, 6-3/8" Long x 6-3/8" Mounting Flange Width, 14-3/16" Overall Height, Metric Thread, Plastic Impeller
Item #: 80030083
Brand: Graymills
Model #: IMV25-F
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Pump Type | Immersion |
| Horsepower | 1/4 |
| Phase | 3 |
| Voltage | 230/460 |
| GPM | 20.00 |
| Shaft Length (Inch) | 7 |
| Housing Material | Cast Iron |
| Shaft Material | Carbon steel |
| Head Pressure | 32.0 |
| Thread Type | Metric |
| Overall Height (Inch) | 14-3/16 |
| Mounting Flange Length (Inch) | 6-3/8 |
| Mounting Flange Width (Inch) | 6-3/8 |
| RPM | 3450.000 |
| Impeller Material | Plastic |
