Thomas & Betts - 2 AWG Noninsulated Compression Connection Rectangle Ring Terminal - 13/32" Stud, 4-29/32" OAL x 1-1/2" Wide, Tin Plated Aluminum Contact
Item #: 73123689
Brand: Thomas & Betts
Model #: ASL60-22
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Terminal Type | Rectangle |
| Insulation Type | NonInsulated |
| Connection Type | Compression |
| Compatible Wire Size (AWG) | 2 |
| Compatible Wire Size (kcmil) | 600 |
| Stud Size (Inch) | 13/32 |
| Contact Material | Aluminum |
| Thickness (Inch) | 3/8 |
| Ring Width (Inch) | 1-1/2 |
| Overall Length (Inch) | 4-29/32 |
| Contact Plating | Tin |
| Standards Met | AL9CU; CSA Certified; RoHS Compliant; UL 486B; UL File E9809; UL Listed |
