Thomas & Betts - 6 AWG Noninsulated Compression Connection Square Ring Terminal - 5/16" Stud, 3" OAL x 1-1/8" Wide, Tin Plated Aluminum Contact
Item #: 73123671
Brand: Thomas & Betts
Model #: ASL30-21
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Terminal Type | Square |
| Insulation Type | NonInsulated |
| Connection Type | Compression |
| Compatible Wire Size (AWG) | 6 |
| Compatible Wire Size (kcmil) | 300 |
| Stud Size (Inch) | 5/16 |
| Contact Material | Aluminum |
| Thickness (Inch) | 1/2 |
| Ring Width (Inch) | 1-1/8 |
| Overall Length (Decimal Inch) | 3 |
| Contact Plating | Tin |
| Standards Met | AL9CU; CSA Certified; RoHS Compliant; UL 486B; UL File E9809; UL Listed |
