Dumont Minute Man - 7/16" x 14" Overall Length, 7/16" Pilot Hole Diam, Square Broach
Item #: 66419060
Brand: Dumont Minute Man
Model #: 66411
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
| Product Specifications | |
|---|---|
| Square Size (Inch) | 7/16 |
| Pilot Hole Diameter (Inch) | 7/16 |
| Minimum Length of Cut (Inch) | 5/16 |
| Maximum Length of Cut (Inch) | 1 |
| Minimum Dimension Across Corners (Decimal Inch) | 0.6140 |
| Maximum Dimension Across Corners (Decimal Inch) | 0.6160 |
| Overall Length (Inch) | 14 |
| Pressure Required for Maximum Length of Cut (Lb.) | 3090 |
| Tooth Pitch (Inch) | 7/32 |
| Minimum Tolerance (Decimal Inch) | 0.4385 |
| Maximum Tolerance (Decimal Inch) | 0.4395 |
| Broach Material | High Speed Steel |
