Rotor Clip - 0.01" Thick, Phosphate Finish, Steel Self Locking Internal Retaining Ring - Grade 1060-1090
Item #: 67158006
Brand: Rotor Clip
Model #: TI-37ST PA
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Self Locking |
| Material | Steel |
| System of Measurement | Inch |
| Bore Diameter (Inch) | 3/8 |
| Bore Diameter (Decimal Inch) | 0.3750 |
| Bore Diameter (mm) | 9.53 |
| Inside Diameter (Decimal Inch) | 0.1750 |
| Military Specification | Does Not Meet Military Specifications |
| Ring Thickness (Decimal Inch) | 0.0100 |
| Material Grade | 1060-1090 |
| Finish/Coating | Phosphate |
| Number of Prongs | 6 |
| Minimum Bore Diameter (Decimal Inch) | 0.3740 |
| Maximum Bore Diameter (Decimal Inch) | 0.3760 |
| Inside Diameter Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Ring Thickness Tolerance (Decimal Inch) | -0.001 to 0.001 |
| Thrust Load (Lb.) | 76.00 |
| Hardness | Rockwell 15N 84-86 |
| Fastener Standard | SAE 1060-1090; UNS G10600-G10900 |
