Abbott Workholding Products - Serrated Attachment, Square Soft Lathe Chuck Jaw - 3 Jaws, Aluminum, 1-3/4" Btw Mount Hole Ctrs, 5-1/2" Long x 2" Wide x 3" High, 3/4" Groove, 5/8" Fastener
Item #: 66154378
Brand: Abbott Workholding Products
Model #: 12A15-8
Exact Tooling IR#: 04
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
| Product Specifications | |
|---|---|
| Jaw Type | Square |
| Material | Aluminum |
| Jaw Interface Type | Serrated |
| Maximum Compatible Chuck Diameter (Inch) | 12 |
| Maximum Compatible Chuck Diameter (Decimal Inch) | 12.0000 |
| Maximum Compatible Chuck Diameter (mm) | 304.80 |
| Minimum Compatible Chuck Diameter (mm) | 254.00 |
| Minimum Compatible Chuck Diameter (Decimal Inch) | 10.0000 |
| Minimum Compatible Chuck Diameter (Inch) | 10 |
| Overall Height (mm) | 76.20 |
| Overall Height (Inch) | 3 |
| Groove Width (mm) | 19.05 |
| Groove Width (Decimal Inch) | 0.7500 |
| Distance Between Mount Hole Centers (mm) | 44.45 |
| Distance Between Mount Hole Centers (Decimal Inch) | 1.7500 |
| Jaw End Shape | Pointed |
| Fastener Size (Inch) | 5/8 |
| Fastener Size (Decimal Inch) | 0.6250 |
| Number of Jaws | 3 |
| Overall Width/Diameter (mm) | 50.80 |
| Overall Width/Diameter (Inch) | 2 |
| Overall Width/Diameter (Decimal Inch) | 2.0000 |
| Overall Length (Inch) | 5-1/2 |
| Overall Length (Decimal Inch) | 5.5000 |
| Overall Length (mm) | 139.70 |
| Tapped Hole Size | 5/16-18 |
| Material Grade | 6061-T6 |
