Abbott Workholding Products - 3/32" x 90° Serrated Attachment, Square Soft Lathe Chuck Jaw - 3 Jaws, Aluminum, 1-1/2" Btw Mount Hole Ctrs, 8-1/4" Long x 2-1/2" Wide x 3" High, 1.004" Groove, 0.7874" & 20mm Fastener
Item #: 66153388
Brand: Abbott Workholding Products
Model #: SMW20A
Exact Tooling IR#: 04
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
| Product Specifications | |
|---|---|
| Jaw Type | Square |
| Material | Aluminum |
| Jaw Interface Type | 3/32" x 90 Serrated |
| Maximum Compatible Chuck Diameter (Inch) | 20 |
| Maximum Compatible Chuck Diameter (Decimal Inch) | 20.0000 |
| Maximum Compatible Chuck Diameter (mm) | 508.00 |
| Overall Height (mm) | 76.20 |
| Overall Height (Inch) | 3 |
| Groove Width (mm) | 25.50 |
| Groove Width (Decimal Inch) | 1.0040 |
| Distance Between Mount Hole Centers (mm) | 38.00 |
| Distance Between Mount Hole Centers (Decimal Inch) | 1.4960 |
| Jaw End Shape | Pointed |
| Fastener Size (mm) | 20.00 |
| Fastener Size (Decimal Inch) | 0.7874 |
| Number of Jaws | 3 |
| Overall Width/Diameter (mm) | 63.50 |
| Overall Width/Diameter (Inch) | 2-1/2 |
| Overall Width/Diameter (Decimal Inch) | 2.5000 |
| Overall Length (Inch) | 8-1/4 |
| Overall Length (Decimal Inch) | 8.2500 |
| Overall Length (mm) | 209.55 |
| Material Grade | 6061-T6 |
