Indexable Drill Insert: XCET0627Q H210T, Solid Carbide
Item #: 59424838
Brand: Allied Machine and Engineering
Model #: 11214549
Product Specifications
| Insert Style | XCET |
| Insert Material | Carbide |
| Manufacturer Grade | H210T |
| Inscribed Circle (Decimal Inch) | 0.2560 |
| Corner Radius (Decimal Inch) | 0.0080 |
| Chipbreaker | 27Q |
| Series | EC 12 |
| Relief Angle | 7 |
| Primary Workpiece Material | Universal |
| Primary Workpiece Material Code | S; K; M; N |
| Standards | ISO 9001:2015 |
| Insert Size | 060202 |
| Length (Decimal Inch - 4 Decimals) | 0.236 |
| Included Angle Degree | 88 |
| Thickness (Decimal Inch - 4 Decimals) | 0.094 |
| Coating/Finish | Bright/Uncoated |
| Insert Size Code | 06 |
| UNSPSC Code | 23242105 |
| Insert Style | XCET |
| Insert Material | Carbide |
| Manufacturer Grade | H210T |
| Inscribed Circle (Decimal Inch) | 0.2560 |
| Corner Radius (Decimal Inch) | 0.0080 |
| Chipbreaker | 27Q |
| Series | EC 12 |
| Relief Angle | 7 |
| Primary Workpiece Material | Universal |
| Primary Workpiece Material Code | S; K; M; N |
| Standards | ISO 9001:2015 |
| Insert Size | 060202 |
| Length (Decimal Inch - 4 Decimals) | 0.236 |
| Included Angle Degree | 88 |
| Thickness (Decimal Inch - 4 Decimals) | 0.094 |
| Coating/Finish | Bright/Uncoated |
| Insert Size Code | 06 |
| UNSPSC Code | 23242105 |
| MSC Part # | 59424838 |
| Mfr Part # | 11214549 |
| Country of Origin Country of Origin is subject to change | Austria |
