Scientific Cutting Tools - 1/4-28" Port, 0.575" Spotface Diam, Plain Pilot, Carbide Tipped Porting Tool
Item #: 44075752
Brand: Scientific Cutting Tools
Model #: MS33649-1S
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | AS 5202; MS 33649 |
| Pilot Type | Plain |
| Port Thread Size (Decimal Inch) | 0.2500-28 |
| Port Thread Size (Inch) | 1/4-28 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 1.000 |
| Minimum Pilot Diameter (Decimal Inch) | 0.2170 |
| Maximum Pilot Diameter (Decimal Inch) | 0.2665 |
| Spotface Diameter (Decimal Inch) | 0.5750 |
| Pilot Length (Decimal Inch) | 0.2740 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | Bright |
| Head Length (Decimal Inch) | 1.0000 |
| Overall Length (Decimal Inch) | 3.0000 |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Shank Length (Decimal Inch) | 2.0000 |
| Seal Angle | 30 |
| Thread Type | UNJF |
| Flute Type | Straight |
| Number of Flutes | 3 |
