Climax Metal Products - M8 Thread, 1-5/8" Bore Diam, 96mm OD, Shaft Locking Device - 7 Screws, 28,741 Lb Axial Load, 3.78" OAW, 1.969" Thrust Ring Width, 1,946 Ft/Lb Max Torque
Item #: 64650047
Brand: Climax Metal Products
Model #: C600E-162
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M8 |
| Bore Diameter (Inch) | 1-5/8 |
| Bore Diameter (Decimal Inch) | 1.6250 |
| Outside Diameter (Decimal Inch) | 3.7800 |
| Outside Diameter (mm) | 96.0000 |
| Thrust Ring Width (Decimal Inch) | 1.969 |
| Overall Width (Decimal Inch) | 3.7800 |
| Axial Load Lbs (Pounds) | 28741 |
| Maximum Torque (Ft/Lb) | 1946 |
| Number of Screws | 7.000 |
| Screw Seating Torque (In/Lb) | 264.000 |
