Climax Metal Products - M12 Thread, 4-1/4" Bore Diam, 197mm OD, Shaft Locking Device - 15 Screws, 139,189 Lb Axial Load, 7.756" OAW, 4.488" Thrust Ring Width, 24,648 Ft/Lb Max Torque
Item #: 64649890
Brand: Climax Metal Products
Model #: C600E-425
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M12 |
| Bore Diameter (Inch) | 4-1/4 |
| Bore Diameter (Decimal Inch) | 4.2500 |
| Outside Diameter (Decimal Inch) | 7.7560 |
| Outside Diameter (mm) | 197.0000 |
| Thrust Ring Width (Decimal Inch) | 4.488 |
| Overall Width (Decimal Inch) | 7.7560 |
| Axial Load Lbs (Pounds) | 139189 |
| Maximum Torque (Ft/Lb) | 24648 |
| Number of Screws | 15.000 |
| Screw Seating Torque (In/Lb) | 888.000 |
