Climax Metal Products - M6 Thread, 3/4" Bore Diam, 1-1/16" OD, Shaft Locking Device - 4 Screws, 5,012 Lb Axial Load, 1.929" OAW, 0.709" Thrust Ring Width, 157 Ft/Lb Max Torque
Item #: 64642333
Brand: Climax Metal Products
Model #: C170E-075
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M6 |
| Bore Diameter (Inch) | 3/4 |
| Bore Diameter (Decimal Inch) | 0.7500 |
| Outside Diameter (Decimal Inch) | 1.0630 |
| Thrust Ring Width (Decimal Inch) | 0.709 |
| Overall Width (Decimal Inch) | 1.9290 |
| Axial Load Lbs (Pounds) | 5012 |
| Maximum Torque (Ft/Lb) | 157 |
| Number of Screws | 4.000 |
| Contact Pressure on Hub (psi) | 17648.000 |
| Contact Pressure on Shaft (psi) | 25013.000 |
| Screw Seating Torque (In/Lb) | 156.000 |
