Accurate Bushing - 5-1/2" Roller Diam x 2" Width, 1-1/4" Stud Diam x 2-3/4" Length, V Guide Roller - Carbon Steel, 1-3/4" Thread Length, 1-1/4-12 Thread, 4-3/4" OAL, 14,300 Lb Dynamic Cap, 16,000 Lb Static Cap
Item #: 62902853
Brand: Accurate Bushing
Model #: VCR-5-1/2
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | V-Guide Roller |
| Roller Diameter (Decimal Inch) | 5.5000 |
| Roller Diameter (Inch) | 5-1/2 |
| Roller Width (Decimal Inch) | 2.0000 |
| Stud Diameter (Decimal Inch) | 1.2500 |
| Dynamic Load Capacity (Lb.) | 14300 |
| Static Load Capacity (Pounds) | 16000.00 |
| Length (Decimal Inch) | 4.750 |
| Thread Size | 1-1/4-12 |
| Material | Carbon Steel |
| Stud Length (Inch) | 2-3/4 |
| Point Diameter (Inch) | 4 |
| Thread Length (Inch) | 1-3/4 |
