Accurate Bushing - 7/8" Roller Diam x 1/2" Width, 3/8" Stud Diam x 7/8" Length, Sealed Self Lubricating Stud Cam Follower with Nonmetallic Bushing - Carbon Steel, 3/8" Thread Length, 3/8-24 Thread, 1-3/8" OAL
Item #: 62902036
Brand: Accurate Bushing
Model #: BCR-7/8-X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Self-Lubricating Stud Cam Follower with Non-Metallic Bushing |
| Roller Diameter (Decimal Inch) | 0.8750 |
| Roller Diameter (Inch) | 7/8 |
| Roller Width (Decimal Inch) | 0.5000 |
| Stud Diameter (Decimal Inch) | 0.3750 |
| Dynamic Load Capacity (N) | 0 |
| Static Load Capacity | 0 |
| Length (Decimal Inch) | 1.375 |
| Thread Size | 3/8-24 |
| Material | Carbon Steel |
| Stud Length (Decimal Inch) | 0.8750 |
| Stud Length (Inch) | 7/8 |
| Thread Length (Inch) | 3/8 |
