Accurate Bushing - 50mm Roller Diam x 40mm Width, 16mm Stud Diam x 50mm Length, Flanged Load Roller - Carbon Steel, 35mm Thread Length, M16 x 2 Thread, 90mm OAL, 17,000 N Dynamic Cap, 7,200 N Static Cap
Item #: 62894340
Brand: Accurate Bushing
Model #: MFCR-50
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Flanged Load Roller |
| Roller Diameter (mm) | 50.000 |
| Roller Width (mm) | 40 |
| Stud Diameter (mm) | 16.00 |
| Dynamic Load Capacity (N) | 17000 |
| Static Load Capacity | 7200 |
| Length (mm) | 90.00 |
| Thread Size | M16 x 2 |
| Material | Carbon Steel |
| Flange Diameter (mm) | 68.00 |
| Flange Thickness (mm) | 14.00 |
| Stud Length (mm) | 50.00 |
| Thread Length (mm) | 35.00 |
