Accurate Bushing - 52mm Roller Diam x 33.6mm Width, 20mm Stud Diam x 40.5mm Length, Flanged Load Roller - Carbon Steel, 21mm Thread Length, M20 x 1.5 Thread, 74.1mm OAL, 17,000 N Dynamic Cap, 7,200 N Static Cap
Item #: 62894332
Brand: Accurate Bushing
Model #: MFCR-52
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Flanged Load Roller |
| Roller Diameter (mm) | 52.000 |
| Roller Width (mm) | 33.6 |
| Stud Diameter (mm) | 20.00 |
| Dynamic Load Capacity (N) | 17000 |
| Static Load Capacity | 7200 |
| Length (mm) | 74.10 |
| Thread Size | M20 x 1.5 |
| Material | Carbon Steel |
| Flange Diameter (mm) | 66.00 |
| Flange Thickness (mm) | 10.80 |
| Stud Length (mm) | 40.50 |
| Thread Length (mm) | 21.00 |
