Accurate Bushing - 76mm Roller Diam x 52mm Width, 30mm Stud Diam x 69.5mm Length, Flanged Load Roller - Carbon Steel, 40mm Thread Length, M30 x 3.5 Thread, 121.5mm OAL, 63,600 N Dynamic Cap, 89,000 N Static Cap
Item #: 62894290
Brand: Accurate Bushing
Model #: MFCR-76
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Flanged Load Roller |
| Roller Diameter (mm) | 76.000 |
| Roller Width (mm) | 52 |
| Stud Diameter (mm) | 30.00 |
| Dynamic Load Capacity (N) | 63600 |
| Static Load Capacity | 89000 |
| Length (mm) | 121.50 |
| Thread Size | M30 x 3.5 |
| Material | Carbon Steel |
| Flange Diameter (mm) | 98.00 |
| Flange Thickness (mm) | 14.00 |
| Stud Length (mm) | 69.50 |
| Thread Length (mm) | 40.00 |
