U.S. Tsubaki - 31 Teeth, 1/2" Chain Pitch, Chain Size 40, Plain Bore Sprocket - 5/8" Bore Diam, 4.942" Pitch Diam, 5.22" Outside Diam
Item #: 57276032
Brand: U.S. Tsubaki
Model #: 40B31
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Plain Bore Sprocket |
| Number of Teeth | 31 |
| Chain Pitch (Inch) | 0.500 |
| Chain Size Number | 40 |
| Maximum Bore Diameter (Inch) | 2-1/4 |
| Bore Diameter (Inch) | 5/8 |
| Bore Diameter (mm) | 15.875 |
| Outside Diameter (Decimal Inch) | 5.2200 |
| Pitch Diameter (Decimal Inch) | 4.9420 |
| PSC Code | 3020 |
