Scientific Cutting Tools - 7/16-20" Port, 0.676" Spotface Diam, 3/8" Tube Outside Diam, Reamer Pilot, Carbide Tipped Porting Tool
Item #: 44064400
Brand: Scientific Cutting Tools
Model #: RPT-6A
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Pilot Type | Reamer |
| Port Thread Size (Decimal Inch) | 0.4370-20 |
| Port Thread Size (Inch) | 7/16-20 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 6.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 0.375 |
| Tube Outside Diameter Compatibility (Inch) | 3/8 |
| Minimum Pilot Diameter (Decimal Inch) | 0.3920 |
| Maximum Pilot Diameter (Decimal Inch) | 0.4650 |
| Spotface Diameter (Decimal Inch) | 0.6760 |
| Pilot Length (Decimal Inch) | 0.4715 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 1.5300 |
| Overall Length (Decimal Inch) | 3.5300 |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Shank Length (Decimal Inch) | 2.0000 |
| Seal Angle | 21 |
| Thread Type | UNJF |
| Flute Type | Straight |
| Number of Flutes | 4 |
