Accurate Bushing - 62mm Roller Diam x 29mm Width, 24mm Stud Diam x 49.5mm Length, Sealed Stud Cam Follower - Carbon Steel, 25mm Thread Length, M24x1.5 Thread, 80mm OAL, 41,500 N Dynamic Cap, 91,000 N Static Cap
Item #: 55247274
Brand: Accurate Bushing
Model #: MCRV-62-S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower |
| Roller Diameter (mm) | 62.000 |
| Roller Width (mm) | 29 |
| Stud Diameter (mm) | 24.00 |
| Dynamic Load Capacity (N) | 41500 |
| Static Load Capacity | 91000 |
| Length (mm) | 80.00 |
| Thread Size | M24x1.5 |
| Material | Carbon Steel |
| Stud Length (mm) | 49.50 |
| Thread Length (mm) | 25.00 |
| Roller Type | Full Complement |
