Accurate Bushing - 90mm Roller Diam x 35mm Width, 30mm Stud Diam x 63mm Length, Sealed Stud Cam Follower - Carbon Steel, 32mm Thread Length, M30x1.5 Thread, 100mm OAL, 60,000 N Dynamic Cap, 142,000 N Static Cap
Item #: 55247241
Brand: Accurate Bushing
Model #: MCRV-90-S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower |
| Roller Diameter (mm) | 90.000 |
| Roller Width (mm) | 35 |
| Stud Diameter (mm) | 30.00 |
| Dynamic Load Capacity (N) | 60000 |
| Static Load Capacity | 142000 |
| Length (mm) | 100.00 |
| Thread Size | M30x1.5 |
| Material | Carbon Steel |
| Stud Length (mm) | 63.00 |
| Thread Length (mm) | 32.00 |
| Roller Type | Full Complement |
