Accurate Bushing - 52mm Roller Diam x 24mm Width, 20mm Stud Diam x 40.5mm Length, Sealed Stud Cam Follower with Hex - Carbon Steel, 21mm Thread Length, M20 x 1.5 Thread, 66mm OAL, 28,000 N Dynamic Cap, 59,000 N Static Cap
Item #: 55246847
Brand: Accurate Bushing
Model #: MCRV-52-SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower with Hex |
| Roller Diameter (mm) | 52.000 |
| Roller Width (mm) | 24 |
| Stud Diameter (mm) | 20.00 |
| Dynamic Load Capacity (N) | 28000 |
| Static Load Capacity | 59000 |
| Length (mm) | 66.00 |
| Thread Size | M20 x 1.5 |
| Material | Carbon Steel |
| Stud Length (mm) | 40.50 |
| Thread Length (mm) | 21.00 |
| Roller Type | Full Complement |
