U.S. Tsubaki - 31 Teeth, 3/4" Chain Pitch, Chain Size 60, Plain Bore Sprocket - 3/4" Bore Diam, 7.413" Pitch Diam, 7.83" Outside Diam
Item #: 54198577
Brand: U.S. Tsubaki
Model #: 60B31
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Plain Bore Sprocket |
| Number of Teeth | 31 |
| Chain Pitch (Inch) | 0.750 |
| Chain Size Number | 60 |
| Maximum Bore Diameter (Inch) | 2-3/4 |
| Bore Diameter (Inch) | 3/4 |
| Bore Diameter (mm) | 19.050 |
| Outside Diameter (Decimal Inch) | 7.8300 |
| Pitch Diameter (Decimal Inch) | 7.4130 |
| PSC Code | 3020 |
