Thomas & Betts - 4/0 AWG Noninsulated Compression Connection Square Ring Terminal - 1/2" Stud, 2-3/4" OAL x 1-3/16" Wide, Copper Contact
Item #: 54057203
Brand: Thomas & Betts
Model #: 31013
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Terminal Type | Square |
| Insulation Type | NonInsulated |
| Connection Type | Compression |
| Compatible Wire Size (AWG) | 4/0 |
| Compatible Wire Size (kcmil) | 300 |
| Stud Size (Inch) | 1/2 |
| Contact Material | Copper |
| Thickness (Inch) | 5/16 |
| Ring Width (Inch) | 1-3/16 |
| Overall Length (Inch) | 2-3/4 |
| Standards Met | CSA Certified; RoHS Compliant; UL File E9809; UL Listed |
